It has strong creep resistance and good balance of rigidity and toughness. It is very durable and has low sag when being processed. Pipes produced using this resin have good strength, rigidity and impact resistance and excellent property of SCG and RCP.
Application of the Product
HDPE pipe grade can be used in the production of pressure pipes, such as pressurized water pipes, fuel gas pipelines and other industrial pipes. It can also be used for making non-pressure pipes such as double-wall corrugated pipes, hollow-wall winding pipes, silicon-core pipes, agricultural irrigation pipes and aluminum-plastics compound pipes. In addition, through reactive extrusion (silane cross-linking), it can be used for producing crosslinked polyethylene pipes (PEX) for supplying cold and hot water.
SINOPEC SABIC Tianjin Petrochemical Co.Ltd. Product Quality Certificate
Product name:High-density resin PN049 Sampling Point:PE-7004 Product Code:PN049-030-122 Sampling Date:2021-04-12 Product number：SIHD1412C2 Signing date:2021-04-13 | |||
Analysis Item | Limited | Test Result | Test Methods |
Color pellets,g/kg | ≤20 | 3 | SH/T 1541.1-2019 |
Snakes and tail pellets,g/kg | report | 3 | SH/T 1541.1-2019 |
Big and small pellets,g/kg | report | 0 | SH/T 1541.1-2019 |
Melt mass flow rate,g/10min | 0.20-0.35 | 0.26 | GB/T 3682.1-2018 |
density | 0.946-0.952 | 0.950 | GB/T 1033.2-2010 |
Tensile stress at yield,MPa | ≥21.0 | 23.3 | GB/T 1040.2-2006 |
Tensile elastic modulus | ≥500 | 882 | GB/T 1040.2-2006 |
Flexual modulus,MPa | ≥760 | 1047 | GB/T 9341-2008 |
Charpy impact strength,KJ/m2 | ≥20.0 | 37.8 | GB/T 1043.1-2008 |
Deformation temperature under load | ≥50 | 77 | GB/T 1634.2-2019 |
Water content,mg/KG | ≤300 | 14 | SH/T 1770-2010 |
Volatile content,mg/kg | report | 213 | GB/T 15558.1-2015 |
Oxidative induction time,min | ≥40 | 78.3 | GB/T 19466.6-2009 |
Nominal strain at break，% | ≥350 | 560 | GB/T 1040.2-2006 |
